Zinc Plated M6 to M16 Carbon Steel Hex Head Coarse Thread Wood Screws

Product Overview

Zinc plated carbon steel wood screws with external hex heads and coarse threads. The size table lists all 81 available model combinations, including each listed nominal length and hex width across flats.

Specifications

Company SKU	SCR-02
Product type	Hex head wood screw
Material	Carbon steel
Surface finish	Zinc plated
Head type	External hex head
Thread form	Coarse thread
Thread designations	M6; M8; M10; M12; M16
Origin	China

Available Variants

Size designation	Thread designation	Nominal length (mm)	Hex across flats (mm)
M6 x 20	M6	20	10
M6 x 25	M6	25	10
M6 x 30	M6	30	10
M6 x 35	M6	35	10
M6 x 40	M6	40	10
M6 x 45	M6	45	10
M6 x 50	M6	50	10
M6 x 60	M6	60	10
M6 x 70	M6	70	10
M6 x 80	M6	80	10
M6 x 90	M6	90	10
M6 x 100	M6	100	10
M6 x 110	M6	110	10
M6 x 120	M6	120	10
M8 x 25	M8	25	13
M8 x 30	M8	30	13
M8 x 35	M8	35	13
M8 x 40	M8	40	13
M8 x 45	M8	45	13
M8 x 50	M8	50	13
M8 x 60	M8	60	13
M8 x 70	M8	70	13
M8 x 80	M8	80	13
M8 x 90	M8	90	13
M8 x 100	M8	100	13
M8 x 110	M8	110	13
M8 x 120	M8	120	13
M8 x 130	M8	130	13
M8 x 140	M8	140	13
M8 x 150	M8	150	13
M8 x 160	M8	160	13
M8 x 180	M8	180	13
M8 x 200	M8	200	13
M10 x 30	M10	30	17
M10 x 40	M10	40	17
M10 x 50	M10	50	17
M10 x 60	M10	60	17
M10 x 70	M10	70	17
M10 x 80	M10	80	17
M10 x 90	M10	90	17
M10 x 100	M10	100	17
M10 x 110	M10	110	17
M10 x 120	M10	120	17
M10 x 130	M10	130	17
M10 x 140	M10	140	17
M10 x 150	M10	150	17
M10 x 160	M10	160	17
M10 x 180	M10	180	17
M10 x 200	M10	200	17
M10 x 220	M10	220	17
M10 x 240	M10	240	17
M12 x 50	M12	50	19
M12 x 60	M12	60	19
M12 x 70	M12	70	19
M12 x 80	M12	80	19
M12 x 90	M12	90	19
M12 x 100	M12	100	19
M12 x 110	M12	110	19
M12 x 120	M12	120	19
M12 x 130	M12	130	19
M12 x 140	M12	140	19
M12 x 150	M12	150	19
M12 x 160	M12	160	19
M12 x 180	M12	180	19
M12 x 200	M12	200	19
M12 x 220	M12	220	19
M12 x 240	M12	240	19
M12 x 260	M12	260	19
M12 x 280	M12	280	19
M12 x 300	M12	300	19
M16 x 100	M16	100	24
M16 x 110	M16	110	24
M16 x 120	M16	120	24
M16 x 130	M16	130	24
M16 x 140	M16	140	24
M16 x 150	M16	150	24
M16 x 160	M16	160	24
M16 x 170	M16	170	24
M16 x 180	M16	180	24
M16 x 200	M16	200	24
M16 x 250	M16	250	24

Packing & Delivery

Packing

· Protective materials are selected to suit the product's shape, size and weight.

· Outer cartons are selected for the product and export transport requirements.

· Small parts are bagged by model and specification, with product and quantity labels.

· Corner protection, reinforcement or pallets are arranged as required.

· Logo, packing dimensions and shipping marks can be customized to order requirements.

Delivery

· Sample orders: 3–5 working days.

· Bulk orders: 10–20 working days, depending on order quantity.

· In-stock items: dispatch within 48 hours.

· Shipping options: DHL, FedEx or sea freight.

· Delivery schedules are confirmed with the order.
