Countersunk Carbon Steel Winged Self Drilling Screws for Timber to Metal Connections
Countersunk Carbon Steel Winged Self Drilling Screws for Timber to Metal Connections
Product Overview
Carbon steel self drilling screws with countersunk heads and wings for timber to metal connections. Three CDWW models are listed with TP25 recess codes, nominal lengths and the treated timber board thickness ranges shown below.
Specifications
|
Company SKU |
SCR-11 |
|
Product type |
Winged self drilling wood screw |
|
Model series |
CDWW |
|
Material |
Carbon steel |
|
Head type |
Countersunk |
|
Recess code |
TP25 |
|
Application |
Timber to metal connections |
|
Listed carbon steel support thickness |
2–4 mm |
|
Listed aluminum alloy support thickness |
3–5 mm |
|
Boxes per carton |
16 |
|
Origin |
China |
Available Variants
|
Model designation |
Nominal length (mm) |
Listed treated timber board thickness (mm) |
Pieces per box |
|---|---|---|---|
|
CDWW 4.8 x 55 |
55 |
16–35 |
200 |
|
CDWW 4.8 x 65 |
65 |
26–45 |
180 |
|
CDWW 4.8 x 75 |
75 |
36–55 |
150 |
Packing & Delivery
Packing
· Protective materials are selected to suit the product's shape, size and weight.
· Outer cartons are selected for the product and export transport requirements.
· Small parts are bagged by model and specification, with product and quantity labels.
· Corner protection, reinforcement or pallets are arranged as required.
· Logo, packing dimensions and shipping marks can be customized to order requirements.
Delivery
· Sample orders: 3–5 working days.
· Bulk orders: 10–20 working days, depending on order quantity.
· In-stock items: dispatch within 48 hours.
· Shipping options: DHL, FedEx or sea freight.
· Delivery schedules are confirmed with the order.
-
