Inorganic Pre-Coated Clean Board, Antibacterial Hospital Clean-Room Wall Panel
Product Type Inorganic Pre-Coated Clean Board
Sheet Size 1220x2440mm
Thickness 6-12mm
Rating Class-A with antibacterial coating
Pricing Unit Per sheet
Export Notes A-grade + antibacterial reports on request
Available Thickness 6-12mm range
Available Sizes 1220x2440mm standard sheet
Inorganic Pre-Coated Clean Board, Antibacterial Hospital Clean-Room Wall Panel
FB-110 is an inorganic pre-coated clean board with antibacterial coating for hospital and clean-room walls. The 6-12mm panel ships in Class-A grade with a dedicated clean-sector report set.
Key Features
· Inorganic pre-coated board, Class-A
· Antibacterial clean-room coating
· 6-12mm thickness range
· Hospital and medical clean walls
· A-grade plus antibacterial report set
· High-margin clean-sector positioning
Applications
· Fire-rated partition walls and shaft linings in high-rise and public buildings.
· Smoke-exhaust and ventilation duct wrapping systems.
· Hotel, school and hospital joinery using flame-retardant plywood and MDF.
· Clean-room and medical walls with antibacterial pre-coated surfaces.
Specifications
|
Product SKU |
FB-110 |
|
Product Type |
Inorganic Pre-Coated Clean Board |
|
Sheet Size |
1220x2440mm |
|
Thickness |
6-12mm |
|
Rating |
Class-A with antibacterial coating |
|
Pricing Unit |
Per sheet |
|
Export Notes |
A-grade + antibacterial reports on request |
Available Sizes / Colors / Finishes
|
Available Thickness |
6-12mm range |
|
Available Sizes |
1220x2440mm standard sheet |
Product Family Comparison
|
Attribute |
FB-101 |
FB-106 |
FB-109 |
|
Type |
Calcium silicate board |
FR plywood B1 |
BS476 FR plywood, FSC |
|
Format |
1220x2440 sheet, 6-12mm |
1220x2440 sheet, 9mm |
1220x2440 sheet |
|
Primary Use |
Class-A partitions |
Wall and ceiling decor |
Export marine, high-end |
|
Pricing Unit |
Per sheet |
Per sheet |
Per sheet |
Installation
· Board systems install on steel or timber framing at the specified centers; verify stud layout against the approved partition schedule.
· Keep boards dry in storage; cut with dust extraction and seal edges in moisture-sensitive areas.
· Fire-rated assemblies must match the tested build-up: board type, thickness, layers and joint treatment per the fire report.
Packaging & Shipping
|
Packing |
Palletized sheets |
Customization Options
Thickness and coating confirmed per clean-room class; documentation per medical project requirement.
Quality and Compliance
· Applicable certificates and test reports must match the exact model, certificate holder, scope and validity before publication or order release.
· Destination-market requirements for the selected SKU must be reviewed before order release.
FAQ
What information is needed for a quotation?
Provide the required model, specification, color or finish, quantity, destination, packing preference and trade terms.
Where are clean boards used in hospitals?
Operating theaters, ICU corridors and pharmaceutical rooms use pre-coated clean boards for washable, low-particulate walls.
Is the antibacterial claim certifiable?
The antibacterial coating carries a test report; the certificate scope is matched to the destination medical standard.
Request a Project Quotation
Send the required model, specification, color or finish, quantity, destination, packing preference and trade terms to request a written quotation and sample plan.
-
